18 Inch Android Industrial Panel PC | IP306-185
18 Inch Android Industrial Panel PC with IP65 front, Wi-Fi 5, and wide temp range for industrial automation.
-
18.5-inch 10-point capacitive touch for precise and responsive operation in industrial control and display applications
-
Android 12 OS with Rockchip industrial-grade ARM processor for stable performance and wide app compatibility
-
Wi-Fi 5, Bluetooth 5.0, and optional 4G module for fast and flexible connectivity
-
IP65-rated front panel with EMI resistance for reliable operation in harsh industrial environments
-
Wide temperature range (-20°C to 60°C) and 12V–24V wide voltage input to suit various power and climate conditions
IP306-180 18 Inch Android Industrial Panel PC – Advanced Performance for Industrial Applications
The IP306-180 18 Inch Android Industrial Panel PC is designed for demanding environments that require reliability, precision, and long-term stability. Powered by a Rockchip industrial-grade ARM processor and running Android 12, it delivers smooth multitasking, fast response, and wide compatibility with industrial applications.
Large Touchscreen for Enhanced Productivity
Featuring a 18.5-inch 10-point capacitive touchscreen, this panel PC ensures highly accurate touch input, enabling operators to interact with complex control interfaces effortlessly. Its wide viewing angle and high brightness make it ideal for control rooms, manufacturing dashboards, and factory automation systems.
Flexible Connectivity and Installation Options
Built with Wi-Fi 5, Bluetooth 5.0, and optional 4G LTE expansion, the IP306-180 provides stable network access whether in a connected facility or remote industrial site. Standard PPC hooks and VESA mount compatibility allow for wall-mounted or desktop configurations, making it adaptable to various workspace layouts.
Durable, Reliable, and Ready for Harsh Environments
Engineered with an IP65-rated front panel to resist dust and water, and equipped with electromagnetic interference (EMI) protection, this panel PC ensures dependable operation even in high-interference zones. Its -20°C to 60°C operating temperature range and 12V–24V wide voltage input allow it to withstand extreme climate and unstable power conditions.
Why Valano Android Industrial Panel PC ?
By integrating robust hardware with advanced software, the IP306-180 reduces downtime, enhances process visibility, and supports industrial automation workflows. Its flexible connectivity and rugged design make it a cost-effective, future-ready solution for sectors like smart manufacturing, logistics control, and public information systems.
| Mode | IP306-180 |
| Processor System | |
| CPU | RK3568 Quad core 64 bit ARM V8.2 Cortex-A55 ,up to 2.0 GHz |
| GPU | Mali-G52-2EE |
| Memory | RAM 4GB onboard ROM 64GB |
| OS | |
| Operating System | Android 12 |
| Display | |
| Display | Type: LCD Size: 18.5 inch 16：9 Resolution: 1920*1080 Brightness: 250 cd/㎡ |
| Touch Pannel | 10 PCAP |
| WIFI | |
| WIFI | 802.11a/b/g/n/ac Frequency 2.4G+5.8G dual band WIFI |
| Bluetooth | BT5.0 |
| 2G/3G/4G | Optional: M. 2 interfaces, USB&PCIE signal compatibility Meg 750 LTE-FDD:B1/3/5/7/8/20 LTE-TDD:B40 WCDMA:B1/5/8 GSM:900/1800 |
| I/O Interface | |
| USB | Standard USB-A USB3.0 *1 USB3.0 *1 OTG+USB2.0 *2 |
| DC IN | Power interface DC IN 12V（Support 12–24V） |
| Audio | ∮3.5mm Standard Earphone Jack *1 |
| LAN | RJ45 *1 (10M/100M/1000M adaptive) |
| COM | DB9 PORT RS232 *2 (Mainboard switchable to RS485：RS485*1，RS232*1) |
| HDMI | HDMI *1 |
| Environment | |
| Working temperature | -20 °C to 60 °C |
| Storage temperature | -30 °C to 70 °C |
| Humidity | 95% Non-Condensing |
| Electrostatic discharge | ± 15kV air discharge, ± 8kV contact discharge |
| Power Adaptor | AC100V ~ 240V、50Hz/60Hz output DC 12V/4A |
| Mechanical | |
| Material | PC+10%GF + galvanized sheet metal+aluminum alloy main body shell |
| Dimension | 457*279*54 mm |
| Weight | 3.5KG |
