15.6 inch Industrial Touch Screen All in One Panel PC | IP105-156

IP105-156: Industrial Touch Screen All-in-One Panel PC: 15.6-Inch Solution

The 15.6-inch Industrial Panel PC is a powerful and durable solution designed for demanding industrial environments. With its high-resolution 1920×1080 display and optional capacitive touch (G+G) technology, it ensures an excellent visual experience and high-touch accuracy, supporting 10-point touch. For those who prefer a traditional interface, an optional resistive touch screen is also available.

Robust and Durable Build for Harsh Environments

Crafted with a rugged aluminum alloy die-cast casing, this Industrial Panel PC is designed for stability and long-lasting performance. Its fanless passive cooling system guarantees silent operation, protecting against dust and vibration. Perfect for environments that require minimal maintenance and maximum reliability.

Powered by Intel® Celeron® Processors

Equipped with Intel® Celeron® Tiger Lake UP3 or Alder Lake-U/P/H series chips, the IP105-156 ensures a seamless computing experience. The high-performance processors are ideal for industrial applications that require fast and consistent operation.

Extensive Connectivity for Versatile Use

With multiple I/O options, including 2 Intel Gigabit Ethernet ports, 4 USB 3.0 ports, 1 HDMI port, 2 COM ports, and more, this system is highly versatile. RS-232/485 communication modes and optional additional COM ports expand its capabilities for industrial automation and control systems.

Enhanced System Protection and Recovery

The wide voltage input (DC 9-36V) comes with built-in protection against short circuits, overvoltage, overcurrent, and reverse polarity. Additionally, the OS Recovery feature offers a one-key system restore function, ensuring that in the case of a power failure or software issue, the system can be easily restored with minimal service costs.

Ideal for Industrial Applications

This Panel PC is built to perform in challenging conditions with an operational temperature range of -10°C to 60°C and a storage temperature of -20°C to 85°C. Whether embedded, wall-mounted, or used on a desktop stand, the IP105-156 can fit seamlessly into any industrial setup.

Frequently Asked Questions (FAQ)

1. What is the difference between capacitive touch and resistive touch screens?

Answer: Capacitive touch screens offer higher precision, faster response time, and support multi-touch functionality (10 points in this model). They are more durable and sensitive to the lightest touch. In contrast, resistive touch screens rely on pressure and are more affordable but less responsive to light touches.

2. Can I use this Industrial Panel PC in extreme temperatures?

Answer: Yes, the 15.6-inch Industrial Panel PC is built to operate in a wide range of temperatures. It functions in environments with operating temperatures ranging from -10°C to 60°C and can store data in temperatures as low as -20°C to 85°C.

3. Is the 15.6-inch Industrial Panel PC suitable for outdoor use?

Answer: While the IP105-156 is designed for industrial settings, it is not waterproof and may not be suitable for prolonged outdoor exposure to weather elements. However, its fanless design and dust-resistant properties make it ideal for factory floors, warehouses, and other indoor industrial environments.

3. What operating systems are supported?

Answer: The 15.6-inch Industrial Panel PC supports Windows 10, Windows 11, and Linux, giving you flexibility depending on your business or project needs.
