1U Rackmount Chassis Intel J6412
The F01-1U6412-4L is a high-performance 1U rackmount chassis network security appliance, designed for firewall, VPN, IDS/IPS, and traffic control applications. Featuring an Intel® Elkhart Lake J6412 processor, 4× Gigabit LAN ports, and flexible storage options, this 1U rackmount server delivers enterprise-grade security in a space-saving form factor.
✔ Intel® J6412 Quad-Core Processor – Efficient, low-power computing for network security workloads
✔ 4× Gigabit LAN Ports (Intel WGI210AT) – High-speed networking for firewall and VPN deployments
✔ Dual Storage (mSATA + SATA) – Supports both SSD and HDD for flexible configurations
✔ Compact 1U Rackmount Design (430×300×44mm) – Fits standard server racks while saving space
✔ Industrial-Grade Reliability – Operates in -10°C to 60°C environments, ideal for data centers
✔ Advanced Security Functions – Watchdog, Bypass, PXE boot, and AC power recovery
Why Choose a 1U Rackmount Chassis for Network Security?
-
Space-Efficient – Perfect for crowded server racks, maximizing density without sacrificing performance
-
Scalable – Supports up to 32GB DDR4 RAM for demanding security applications
-
Versatile Deployment – Works as a firewall, VPN gateway, traffic shaper, or IDS/IPS
-
Low Power Consumption – Built-in 75W power supply reduces energy costs
-
Easy Maintenance – Front-accessible ports and hot-swappable storage options
Best Applications for This 1U Rackmount Security Appliance
🔹 Firewall & VPN Gateway – Secure network perimeters with high-speed encryption
🔹 Traffic Shaping & QoS – Control bandwidth usage for optimized network performance
🔹 Intrusion Detection/Prevention (IDS/IPS) – Real-time threat monitoring and blocking
🔹 Content Filtering & Web Security – Enforce policies and block malicious sites
🔹 Network Monitoring & Logging – Capture and analyze traffic for security audits
Ideal for IT Managers & Network Security Professionals
If you need a reliable, compact, and high-performance 1U rackmount chassis for security applications, the F01-1U6412-4L delivers enterprise features at an affordable price. Whether deploying as a firewall, VPN concentrator, or traffic analyzer, this appliance ensures security without compromising on space or efficiency.
| Processor System | |
| CPU | Intel® Elkhart Lake J6412 |
| Memory | |
| Slot Number | 1×SO- DIMM |
| Type | DDR4 3200 |
| Max Size | 32GB (Optional) |
| Channels | Single Channel |
| Storage | |
| mSATA | 1 (Optional) |
| SATA | 1 (Support 2.5-inch or 3.5-inch hard disk) |
| Expansion Slot | |
| Mini-PCIe | 1 |
| SIM Card | 1 |
| PCIex4 | 0 |
| Power Requirements | |
| Input PWR | 4Pin ATX interface |
| Rear IO | |
| LAN | Onboard 4 power supplies (Intel WGI210AT) |
| USB3.0 | 2 |
| Console | 1 |
| HDD LED | 1 |
| PWR LED | 1 |
| VGA | 1 |
| Mechanical & Environment | |
| Dimension | 430×300×44 (W×D×H) |
| Operation | -10~60℃, 10%~90%, non-condensing |
| Storage | -40~85℃, 5%~95%, non-condensing |
Get Free Quote of 1U Rackmount Chassis
